Tennis Court Windscreens & Privacy Screens: Sizing, Installation, Care
A tennis court windscreen provides a consistent visual backdrop and helps obscure activity beyond the fence, including walkways, adjacent courts, parking lots, and neighboring properties. Royal Shade USA offers breathable HDPE privacy mesh for clubs, schools, and residential courts, with listed 90% visibility blockage. Choose the construction and finished size around the existing fence, its condition, and your facility's privacy needs.
What a tennis court windscreen does
The Tennis Queensland Technical Manual for Tennis Facilities explains that windscreens provide a visual background and privacy, may reduce or deflect wind, and add load to fence posts. It also identifies dark backgrounds as helpful for ball definition. These are general facility design principles; a product's visual blockage figure does not establish its wind performance.
Choose the screen around your court's sightlines and privacy needs. If wind management is the main specification, have a qualified installer confirm the product and fence design for the site.
Mesh selection and visual background
The Royal Shade USA Privacy Fence Screen 170 GSM is available in multiple standard heights and lengths with finished black binding and metal grommets. The product details list 90% visibility blockage. Dark green or black panels create a strong backdrop for ball tracking, but the right color depends on the facility and surrounding landscape.
Green mesh panel with black bound edges and corner grommets shown for attachment reference.
For facilities with multiple courts, the same screen color should be carried across the entire bank of courts so the visual environment is consistent.
Height, finished size, and material selection
Start with the usable fence opening, including the attachment space above, below, and beside the panel. Confirm the selected screen's actual finished dimensions before ordering; a nominal height label alone does not establish the fit.
Standard uses 170 GSM HDPE and Plus uses 220 GSM HDPE. GSM measures fabric mass per square meter. Both list 90% visibility blockage, so compare fabric weight, edge construction, and sizing rather than assuming different opacity or wind ratings.
The Heavy Duty Plus Privacy Fence Screen 220 GSM lists a 4-in binding, about 2 in per side, four metal corner grommets, and 4/5/6/8 ft nominal heights by 50 ft lengths. Its finished height is listed 3 in below nominal. Standard sizes include 4 ft, 5 ft, 6 ft, and 8 ft options with varying lengths and colors. Check current availability for the chosen combination.
Plus 220 GSM corner detail
Compare the reinforced border and grommet layout with the fence's available fixing points. Plan how each finished edge will be secured before selecting panel sizes.
Plus 220 GSM green mesh corner finished with black binding and four metal grommets.
Standard 170 GSM vs Plus 220 GSM
Use this comparison to choose the fabric weight, edge finish, and available dimensions that suit the project. Fence capacity and attachment planning remain necessary for either product.
| Feature | Standard 170 GSM | Plus 220 GSM |
|---|---|---|
| Fabric weight | 170 GSM HDPE | 220 GSM HDPE |
| Listed visibility blockage | 90% | 90% |
| Binding | Black binding with grommets around perimeter | 4-in binding, about 2 in per side |
| Corners | Typically four grommets per corner | Four metal grommets per corner |
| Nominal heights | 3, 4, 5, 6, and 8 ft on main listing; height-specific pages may vary | 4, 5, 6, and 8 ft by 50 ft lengths |
| Finished height note | Check selected product page | Listed 3 in below nominal fence height |
Standard offers multiple length combinations; Plus provides a heavier fabric with wider listed binding. Choose the construction and finished size that suit your handling and installation requirements. Neither the GSM number nor the visual blockage percentage specifies an engineering wind rating.
Court-specific measurement worksheet
Measure the enclosure itself: court playing lines do not describe the fence perimeter. Record each straight run separately, with terminal posts, corners, and gate frames marking its boundaries.
For each court or bank of courts, record the following:
- Usable fence height at several points along the run.
- Each straight run, ending at a corner, terminal post, or gate frame.
- Intermediate post spacing and existing attachment points.
- Separate gate measurements, handles, latches, and full swing clearance.
- Slopes, nearby lights, signs, conduit, or other obstructions.
A long panel can span intermediate fence bays when its finished dimensions and attachment layout suit the run. The Chain Link Fence Manufacturers Institute manual calls for wind-load strength analysis of post size and spacing when windscreen or privacy slats are added. Have an installer review the fence and footings before covering an exposed or older enclosure.
For example, a nominal 6 ft Plus screen lists a 69-in finished height. If the usable fence opening is 70 in, the panel may fit vertically with the right fastener positions, but the installer must verify clearance at the top and bottom. A 50 ft factory panel is not a substitute for a 9 ft 6 in run. Either choose a matching factory finished length for the measured run or submit a custom order with confirmed dimensions.
Plan the attachment points
Plan a level top edge and distribute fasteners around the finished perimeter. Check the position from both sides of the fence before fully securing the panel, especially where the ground slopes.
Beige 170 GSM privacy screen shown along a metal fence face with grommet and tie attachment points.
Installation clearance and distributed fastening
Begin with a loose mockup. Check alignment, ground clearance, gate paths, court access, and nearby fixtures. Repair loose posts, damaged rails, or chain link before adding mesh; fabric cannot stabilize a failing fence.
Use suitable outdoor-rated fasteners through the manufacturer's specified grommets or finished attachment points. Distribute tension evenly around the perimeter and follow the product's tensioning instructions without over-tightening. Keep fasteners out of raw mesh. Obtain manufacturer approval before cutting finished fabric, binding, or grommets, including alterations intended to create vents.
Plan gate panels separately and check the full swing of each leaf, including handles, latches, and adjacent screens. Use a panel that preserves normal operation, or leave the gate unscreened if a suitable clearance cannot be maintained.
Schedule installation outside active play and keep tools, ladders, and loose fabric away from occupied courts. Arrange an inspection where posts lean, fittings are loose, or corrosion is visible.
Custom tennis court windscreen order request
The custom made-to-order fence screen is a 170 GSM option for runs outside standard sizes. Its listing describes finished height as approximately 2 in below nominal fence height. Confirm the desired finished dimensions explicitly; this differs from the Plus sizing note.
When requesting a custom tennis court windscreen, include the following in the message:
- Required finished height and width, including binding, for each panel.
- Top, bottom, and end clearances agreed with the installer.
- Panel quantities, separate gate pieces, and color preference.
- Confirmation of the listed 170 GSM custom construction; ask the team about availability if another material is required.
- A sketch showing corners, slopes, and existing fixtures.
Use the contact page to confirm finished measurements, quote, material availability, and current production and delivery dates. Obtain the agreed dimensions in writing. The FAQ page covers general product questions.
Seasonal care and facility purchasing checklist
Gently rinse dust and debris from the mesh and let it dry. Include binding, grommets, fasteners, and fence condition in regular facility inspections, with an additional check after strong weather. Address loose or damaged attachments promptly. Follow the manufacturer's and facility's instructions for severe weather, seasonal removal, and dry storage.
Before placing the facility order:
- Have the installer confirm fence suitability, panel layout, and gate clearances.
- Confirm finished dimensions, quantities, color, current availability, and any custom quote.
- Review the shipping policy and warranty policy, including coverage for the selected product.
- Plan delivery, installation access, and responsibility for ongoing inspections.
The privacy fence screens collection brings the current standard options together. A project can combine suitable factory-finished panels for long runs with confirmed custom pieces for gates or short returns.
Practical FAQ
What does a tennis court windscreen actually do?
It provides visual screening and a backdrop behind play. Royal Shade's mesh lists 90% visibility blockage. That percentage describes visual screening and should not be interpreted as a measured reduction in wind.
What is the difference between 170 GSM and 220 GSM?
GSM is fabric mass per square meter. The Standard screen is 170 GSM HDPE, and the Plus screen is 220 GSM HDPE. Both list 90% visibility blockage. The Plus panel also lists a 4-in binding and four metal corner grommets, but GSM is not a physical thickness, UV rating, or wind-load certification.
How do I measure a tennis court fence for a privacy screen?
Measure the actual fence opening height and the continuous straight runs between terminal posts, corners, and gate frames. Include gate leaves, slopes, and existing attachments. Do not use tennis court playing line lengths as the fence measurement. Record finished height and width for the selected panel.
Can one long panel cover multiple fence bays?
Yes, a long panel may cover multiple bays if its finished size and attachment layout match the run and the fence is structurally sound. You do not have to split at every line post, but fasteners must be placed through manufacturer-specified grommets and distributed along the panel.
Should gate areas be screened separately?
Yes. Gate panels should be measured and planned separately so gates can open fully without hitting handles, latches, posts, or adjacent screens. If the screen would interfere with gate operation, use a narrower panel or leave the gate area unscreened.
Can I cut a tennis court windscreen to fit on site?
Do not cut the finished mesh, binding, or grommets unless the manufacturer approves the alteration. For non-standard court sections, request a custom size with confirmed finished dimensions and clearances instead of altering a factory panel.
